Garrett G25 660 A/R 0,72 Wastegate (Reverse Rotation)

Description

Garrett G25-660 A/R 0,72 Wastegate (Reverse Rotation)

G-Series G25-660 turbochargers from Garrett are compatible with 1.4L – 3.0L engine displacements and capable of producing up to 660 horsepower.

G25-660 Series turbochargers are smaller and outflow all comparable products on the market. Improved durability with better materials can withstand higher temperatures and better safety margins.

The Garrett G-Series G25-660 turbochargers deliver more power and durability in a smaller frame than ever before.

Horsepower: 350 – 660HP
Displacement: 1.4 – 3.0L



Compressor

Exducer: 67mm
Inducer: 54mm
Trim: 65
Material: Forged Billet Aluminum Alloy
A/R: 0.70
Max Flow: 61 lb/min
Max Recommended Speed: 165000 RPM

Compressor Housing Connections

Inlet: 3.0″ Hose Coupler
Outlet: 2.0″ Hose Coupler

Turbine

Exducer: 49mm
Inducer: 54mm
Trim: 84
Material: Mar-M
A/R: 0.72
Max Temp: 1050C / 1922F
Wastegate: Yes 0.5 bar
Divided: No

Turbine Housing Connections

Inlet: 3.0″ V-band
Outlet: 3.5″ V-band

—————-
