Description
This kit bolts onto the lower a-arm pivot locations, but requires welding on new upper arm mounts to the frame. Fabrication is required to mount shock absorbers, bump stop mounts, and limit straps. Fabrication and installation should be completed by a professional. Only built to accept a 12-bolt style race hub, with 5 on 5.5″ or 6 on 5.5 Lug pattern.
Tabbed and slotted boxed upper a-arms
Tabbed and slotted boxed lower a-arms with 1.5″ uniballs
Fabricated 4130 Upright w/ 1″ uniball (designed to accept bolt-on snouts)
Heim steering
Fabricated tie rods
MIG welded components
All necessary bolts included
All heims, uniballs, bushings/sleeves included
Upper Control arm tabs included.
Runs 2.5″ Coilover and 4″ bypass
SPECIFICATIONS
93″ Overall width
17+” useable wheel travel
Options:
BMS 2.5″ Race Hub
Wilwood 12” Brake Kit: +$699
